InfiRay Extended Battery Compartment (SAIM)

Pulsar Merger XT50 Thermal Binoculars with Laser Rangefinder

Thermal performance with class.

The Pulsar Merger LRF represents Pulsar's classic thermal imaging binocular design with an integrated laser rangefinder.

These binoculars are remarkably ergonomic and comfortable. They allow for two-eye observation and reduce eye fatigue. They are equipped with top-tier components that exemplify European quality.

The Merger LRF XT50 is the first pair of thermal imaging binoculars from Pulsar to feature a remarkable 1280×1024, 12µm, <40mK NETD thermal sensor and built-in image stabilisation. These features lend another level of clarity and stability and provide greater observation opportunities without any distractions. Fully kitted out with a wide range of digital functionalities and connectivity options, including a built-in still image and video recorder, Stream Vision 2 compatibility, and a precision laser rangefinder, these binoculars are perfect for long-range, comfortable observation.

Features

European made thermal imaging sensors

Merger LRF Series ensures unrivalled thermal imaging experience. For image capture Merger binoculars use professional-grade, European made thermal imaging sensors:

• 12 micron sensors 1280×1024 and 1024×768 offer high definition image quality.
• 17 micron sensors 640×480 and 384×288 provide extreme thermal sensitivity.

Detailed and sharp image on high zoom

Optical magnification of the unit can be increased by means of digital zoom. Even at the highest level of zoom image detail is sufficient for identifying the smallest object details. Advanced algorithms enhance image quality and help to achieve sharp and detailed image.

Wide field of view

Wide field of view simplifies scanning and spotting hot objects while minimizing effects of image shaking and raising situational awareness. Excellent image detail on base magnification combined with wide field of view ensure improved viewing comfort and scene perception.

Extra-long detection range

Powerful germanium optics combined with professional thermal imaging sensors provide exceptional detection capabilities. Top Merger LRF units can detect hot objects at distances exceeding 2km.

User mode

Use the brightness and contrast adjustments to maximise the detail and informative value of the image in specific observation conditions. The User Mode function saves selected brightness and contrast settings in the device’s memory providing optimal image quality for the next use of the thermal imager immediately, with no additional adjustments needed.

Classic binocular design

Merger LRF thermal imaging binoculars are built with the classic design of daytime binoculars. With a small form factor, these thermal imaging binoculars fit comfortably in the hand, but still offer appealing external aesthetics and exemplary ergonomics. The six function buttons are placed in the comfort access zone and the most used digital device functions are activated with a single touch.

Comfortable viewing experience with both eyes

The Merger LRF binoculars’ optical design takes into account the nature of human vision. It is natural for a person to receive visual information through two visual channels simultaneously. Viewing with two eyes is less tiring than viewing with one. This means better detection of small or faint objects, and better performance in low-contrast scenarios than similar monocular thermal imaging devices with the same technical level. The interpupillary distance in the Merger LRF binoculars is adjustable from 63 to 74 mm in accordance with the individual characteristics of a particular user.

Precise laser rangefinder

Understanding the target distance is an essential factor in making the right decisions. A built-in laser rangefinder allows you to measure distances in single measurements and continuous scanning modes with an accuracy of ± 1 meters for quick and error-free assessment of the situation.

Combined dual battery system

The Merger LRF Series is powered with two rechargeable batteries: one built-in with a capacity of 4 Ah, the other replaceable with a capacity of 3.2 Ah. A single charge guarantees long battery life.

Other Features

• High-quality reinforced magnesium alloy housing
• Built-in photo and video recorder
• Stream Vision 2. Wi-Fi integration with iOS and Android devices
• Improved Wi-Fi connectivity with 2.4 / 5 GHZ waveband support
• High-contrast HD AMOLED displays
• IPX7 Waterproof Rated
• Wide range of operating temperatures (-25 to +50°C)
• A selection of 8 color palettes
• Proximity sensor
• Picture in Picture
• 3 Sensitivity enhancement levels
• Fast aperture F1.0 optics

Specifications

• Main
• Sensor: 1280x1024 @ 12 µm
• Objective lens: F50 / 1.0
• Magnification, x: 2 – 16
• FOV (HxV), degrees: 17.5 х 14
• FOV (HxV), m@100m: 30.7 х 24
• Detection range: 2300 m

Sensor

• Type: uncooled
• Resolution, pixels: 1280x1024
• Pixel pitch, µm: 12
• Sensor NETD, mK: < 40
• Frame rate, Hz: 50

Optics

• Objective lens: F50 / 1.0
• Magnification, x: 2 – 16
• FOV (HxV), m@100m: 30.7 х 24
• FOV (HxV), degrees: 17.5 х 14
• Interpupillary distance adjustment, mm: 62 – 74
• Eye relief, mm: 15

Display

• Type: AMOLED HD
• Resolution, pixels: 1280х960

Laser rangefinder

• Max. measuring range, m: 1500
• Measurement accuracy, m: ± 1
• Safety class for laser equipment according to IEC 60825-1:2014: 1
• Wavelength, nm: 905

Video recorder

• Video / photo resultion, pixel: 1280х960
• Video / photo format: .mp4 / .jpg
• Build-in memory, GB: 64

WI-FI

• Wireless protocol: Wi-Fi
• Wireless standard: IEEE 802.11 b/g/n/ac (WPA)
• Frequency, Ghz: 2.4 / 5

Environmental characteristics

• Degree of protection IP code (IEC60529): IPX7 (waterproof)
• Operating temperature range, °С: -25 – +50

Connections and compatibilities

• Mount type: 1/4" socket
• Supported application: Stream Vision 2

Power supply

• Output voltage, V: 3.7
• Battery type: Dual Li-Ion B-Pack Mini Power System: 2 A·h Changeable Battery (external) / 4.9 A·h Battery (internal)
• Capacity, mAh: 3200 (external) + 4000 (internal)
• Operating time on battery pack, h at t=22°С: 8
• External power supply, V: 5V; 9V (USB Type-C Power Delivery)

Weight & size

• Body material: Magnesium alloy
• Dimensions, mm: 197x140x72
• Weight, kg: 0.95 (batteries included)
• SKU: 77486

The first thermal imaging riflescope with classic design and built-in laser rangefinder

The laser rangefinder is seamlessly integrated into a slim design riflescope. The rangefinder is compact, the receiver and emitter are within clearance limits of a single optical channel. The measuring range is 800 metres – the Thermion 2 LRF provides the hunter with an accurate sense of distance at the hunting site helping to take a precise shot.

Features:
• Variable magnification
• High-precision aiming in the "Picture-in-picture" mode
• 5 individual shooting profiles / 50 zeroing distances
• A selection of 10 reticle shapes in 9 color modes
• Mounting on standard 30 mm rings
• Instant Start-up
• High caliber recoil resistance: 12 gauge, 9.3x64, .375H&H
• Completely waterproof IPX7
• Operating temperature range: -25 to +50 °C
• High contrast HD AMOLED display
• A selection of 8 color palettes
• Wide-angle eyepiece for comfortable observation
• Photo and video recording
• Stream Vision 2. WiFi integration with iOS and Android devices

Specifications:
• Sensor: 384x288 @ 17 µm (NETD <25 mK)
• Objective lens: F50 F/1.0
• Magnification: 3-12x
• Detection range: 1800 m
• Field of view (HxV), degrees / m@100m: 7.5 / 13.1
• Eye relief: 50 mm
• Type: Uncooled
• Resolution: 384x288 Pixels
• Pixel pitch: 17 µm
• NETD: <25 mK
• Frame rate: 50 Hz
• Type: AMOLED
• Resolution: 1024х768 Pixels
• Click value H/V(mm at 100 m): 13 – 3х 6.5 – 6х 3.25 – 12
• Click range H/V(mm at 100 m): 2600 / 2600
• Number of preloaded reticles: 10+
• Video / photo resolution: 1024x768 Pixels
• Video / photo format: .mp4 / .jpg
• Built-in memory: 16 GB
• Wireless Protocol: Wi-Fi
• Wireless Standard: IEEE 802.11 b/g/n/ac (WPA)
• Frequency: 2.4 / 5 GHz
• Degree of protection, IP code (IEC60529): IPX7
• Operating temperature range: -25 – +50 °С
• Max. recoil power on rifled weapon: 6000 Joules
• Compatible mounts: Standard 30 mm Rings
• Supported Application: Stream Vision 2
• Output voltage: 3.7 V
• Battery type: Li-ion APS2
• Capacity: 4900 mAh
• Operating time on battery pack(at t=22°C): 10 hours
• External power supply: 5 V /9 V (USB Type-C Power Delivery)
• Body material: Aluminum
• Dimensions: 420 x 78.5 x 94.5 mm
• Weight: 0.97 Kg

Laser Rangefinder
• Wavelength: 905 nm
• Max. measuring range: 800 m
• Measurement accuracy: ± 1

Warranty period on new thermal optics:
• Pulsar: 3 Year manufacturers warranty
• Guide: 1 Year + Register online and get an extra year: https://www.guideir.com/service/free-extended-warranty
• InfiRay: 2 Year warranty: https://www.infiray.com/uploads/file/after-sales-service-policy.pdf

Please note: Manufacturers warranty period above covers the unit itself and does not cover commercial use. Thermal accessories will have a lesser cover period that what is specified for the units above. The warranty does not cover mis-use or accidental damage caused by the operator.

Guide TU650 640x512 50mm Thermal Scope Laser Rangefinder

The TU 3.0 Series redefines precision optics with advanced thermal imaging, modular design, and AI powered performance. Offered in six sub-series—from ultra-light compact units to dual-spectrum, longrange solutions—they meet the demands of hunters, professionals, and tactical users alike. Featuring AI enhanced imaging, shutterless design, ergonomic controls, IP68 protection, and dual-band Wi-Fi, they deliver reliable performance in any environment.

Hyper-Light Algorithm Ultra-Premium Visuals

Powered by next-gen sensors and the Hyper-light algorithm, the product boosts image quality on multiple levels through improved clarity, reduced noise, optimized contrast, and enhanced resolution of fine details.

Lightweight Design Compact Housing

Compared to the previous generation, TU LRF 3.0 adopts a more compact and lightweight design, making it over 200g lighter than its predecessor with the same configuration. Its slim, metallic housing provides a comfortable grip.

Shutterless Design Uninterrupted Visuals

The innovative shutterless 3.0 technology eliminates the clicking sound and image freezing, ensuring uninterrupted real-time footage during actual hunts, in case any shots are lost or missed during calibration.

Locate with Accuracy Up to 1500m

The TU LRF 3.0 Series integrates a precise laser rangefinder that can easily locate prey up to 1,500 meters, assisting hunters in achieving a successful hunt in the field.

Seamless Control Easy Focus & Zoom

Built on extensive field testing and hunter feedback, TU LRF 3.0 was refined in every detail—from the focus wheel to the zoom lever and button layout. The ergonomic design is crafted for comfort and intuitive control.

Specifications for Guide TU650 640x512 50mm Thermal Scope Laser Rangefinder:

Sensor:

• Type: Uncooled VOx Infrared Detector, 8 to 14µm
• Resolution: 640×512@12µm
• NETD: 18mK
• Frame rate: 50 Hz

Lens:

• Objective lens: 50mm, F1.0
• Field of view: 8.2°×5.0°
• FOV m@100m: 14×9
• Magnification: 3.9x~31.2x
• Detection range: 2600m/2800yd
• Focus: Manual

Display:

• Display type: 0.49'' AMOLED 1920×1080
• Color palettes: White Hot, Black Hot, Red Hot, Green Hot, Iron Red, Blue Hot, Sepia
• Eyepiece: Eye relief: 48mm; Diopter -5 to +5; Zoom: 14x

Hardware:

• Laser rangefinder: 1500m/1630yd
• WIFI: 2.4G, 5G
• Interface: USB-C (Charge/USB2.0)
• Tube diameter: Standard 30 mm
• Others: Microphone, Bluetooth

System:

• Recording function: Photo/Video (Audio recording included)
• Memory capacity: 128GB

Power:

• Battery type: 18500 ×1 Battery (Built-in) and 18650 ×1 Battery (External)
• Operating time: 12 hours

Environmental:

• Operating temp.: -20°C to 50°C / -4°F to +122°F
• Shock: 6000J/1200G
• Encapsulation: IP68

Physical:

• Weight (g/oz): 815/28.75
• Size (mm/in): 377×89×82/14.84×3.50×3.23
• Standard: Device, Lens Cover, Eye Mask, Quick-Release Scope Mount, Carry Bag, 18650 Battery ×2, Battery Charger, 5V 2A Adapter (US or UK or Australia or Europe), USB-A to USB-C Cable, Quick Start Guide, Warranty Card

Guide TU435L 3.0 400x300 35mm Thermal Scope Laser Rangefinder

The TU 3.0 Series redefines precision optics with advanced thermal imaging, modular design, and AI powered performance. Offered in six sub-series—from ultra-light compact units to dual-spectrum, longrange solutions—they meet the demands of hunters, professionals, and tactical users alike. Featuring AI enhanced imaging, shutterless design, ergonomic controls, IP68 protection, and dual-band Wi-Fi, they deliver reliable performance in any environment.

Hyper-Light Algorithm Ultra-Premium Visuals

Powered by next-gen sensors and the Hyper-light algorithm, the product boosts image quality on multiple levels through improved clarity, reduced noise, optimized contrast, and enhanced resolution of fine details.

Lightweight Design Compact Housing

Compared to the previous generation, TU LRF 3.0 adopts a more compact and lightweight design, making it over 200g lighter than its predecessor with the same configuration. Its slim, metallic housing provides a comfortable grip.

Shutterless Design Uninterrupted Visuals

The innovative shutterless 3.0 technology eliminates the clicking sound and image freezing, ensuring uninterrupted real-time footage during actual hunts, in case any shots are lost or missed during calibration.

Locate with Accuracy Up to 1500m

The TU LRF 3.0 Series integrates a precise laser rangefinder that can easily locate prey up to 1,500 meters, assisting hunters in achieving a successful hunt in the field.

Seamless Control Easy Focus & Zoom

Built on extensive field testing and hunter feedback, TU LRF 3.0 was refined in every detail—from the focus wheel to the zoom lever and button layout. The ergonomic design is crafted for comfort and intuitive control.

Specifications for Guide TU435L 3.0 400x300 35mm Thermal Scope Laser Rangefinder:

Sensor:

• Type: Uncooled VOx Infrared Detector, 8 to 14µm
• Resolution: 400×300@12µm
• NETD: 20mK
• Frame rate: 50 Hz

Lens:

• Objective lens: 35mm, F1.0
• Field of view: 7.4°×4.4°
• FOV m@100m: 13×8
• Magnification: 4.4x~17.6x
• Detection range: 1800m/1950yd
• Focus: Manual

Display:

• Display type: 0.49'' AMOLED 1920×1080
• Color palettes: White Hot, Black Hot, Red Hot, Green Hot, Iron Red, Blue Hot, Sepia
• Eyepiece: Eye relief: 48mm; Diopter -5 to +5; Zoom: 14x

Hardware:

• Laser rangefinder: 1500m/1630yd
• WIFI: 2.4G, 5G
• Interface: USB-C (Charge/USB2.0)
• Tube diameter: Standard 30 mm
• Others: Microphone, Bluetooth

System:

• Recording function: Photo/Video (Audio recording included)
• Memory capacity: 128GB

Power:

• Battery type: 18500 ×1 Battery (Built-in) and 18650 ×1 Battery (External)
• Operating time: 12 hours

Environmental:

• Operating temp.: -20°C to 50°C / -4°F to +122°F
• Shock: 6000J/1200G
• Encapsulation: IP68

Physical:

• Weight (g/oz): 780/27.51
• Size (mm/in): 374×89×82/14.72×3.50×3.23
• Standard: Device, Lens Cover, Eye Mask, Quick-Release Scope Mount, Carry Bag, 18650 Battery ×2, Battery Charger, 5V 2A Adapter (US or UK or Australia or Europe), USB-A to USB-C Cable, Quick Start Guide, Warranty Card

Guide TR650 Thermal Scope

The thermal scope TR Series is an economical civilian infrared thermal imaging scope that adopts high sensitivity thermal detector with three different lens options 25 mm, 35 mm, and 50 mm. The TR thermal scope Series offers sharp, detailed images with 640 × 480 IR resolution while retaining accuracy. TR thermal hunting scopes feature a compact size, waterproof and dustproof, high shock resistance, rugged and durable, which performs impressively in harsh weather.

This Thermal imaging unit runs with 18650 Button top type batteries (174169) or (454065)

Thermal Scope Key Features

• 640×480IR resolution
• 50mm F1.0 Focal length
• 8.73°×6.60°FOV
• 1024×768 OLED display
• External LRF (laser Rangefinder) that can measure up to 600m
• Extended Picatinny Mount

Enduring performance, day and night.

Main Thermal Scope Features

• 8 hours super long battery life: Standard 18650 battery provides enough power for up to 8 hours of operation time, ensuring continuous observation without disruptions
• Photo and video recording: Photo and video functions to record wonderful moments at any time,, easy to share
• High definition detector: TR series uses high-quality 12um thermal imaging detectors with 640x480 resolution to offer an exceptionally sharp image and excellent thermal sensitivity in all weather conditions
• One-touch Freeze: Screen freeze for quick and easy zeroing improves accuracy and enhances user convenience, contributing to a better user experience.
• External Laser Range Finder (LRF): With an external laser range finder, the TR series can achieve 600 meters of accurate distance measurement for quick target searching, allowing for direct connection on boot without manual pairing.
• Six Colour Palettes: The 6 colour palettes improve viewing under various conditions. White Hot, Black Hot, and Red Hot are optimal for object detection. Green Hot, Iron Red, and Blue Hot help increase chances for recognition and identification.
• IP67 Protection Rating: With IP67 waterproof and dustproof rating, the TR Series works in high humidity and heavy rain conditions and protects from dust and impact, which features exceptionally high shock resistance up to 800G.
• ?OTA Upgrade: Support device firmware updates by connecting TargetIR for high efficiency.

Thermal Scope Specifications

Sensor

• Type: Uncooled VOx Infrared Detector, 8 to 14 µm
• Resolution: 640×480, 12 µm
• NETD: =30mK
• Frame rate: 50 Hz

Lens

• Focal length: 50 mm, F1.0
• Field of view: 8.73°×6.60°
• Optical zoom: 2.8x
• Digital zoom: 1x ~ 8x
• Focus: Manual

Display

• Display type: 0.39’’ AMOLED
• Resolution: 1024×768
• Eyepiece: Exit pupil distance = 48 mm; Diopter ± 4; Zoom: 14x
• Video output : Analog video

Range Performance

• Detection range: 2000 m

Functions

• Scene modes: Enhanced, Highlight and Natural
• Color palettes: White Hot, Black Hot, Red Hot, Green Hot, Iron Red, Blue Hot
• Recording function: Photo/Video
• WIFI: 2.4G
• Supported Application: TargetIR
• Firmware OTA: Upgrade device firmware via app connection
• Others: PIP, Hot spot tracking, Rough ranging

Power

• Battery type: Single, replaceable 18650 battery
• Operating time: = 8 hours

Interface

• USB: USB Type-C
• Mechanical interface: Picatinny

System

• Language settings: English / Russian / German / French / Italian / Spanish / Japanese / Korean
• Memory capacity: 32GB

Environmental

• Operating temperature: -30°C to 50°C
• Storage temperature: -45°C to 70°C
• Humidity: 10 % to 95 % non-condensing
• Shock: 800 G at 1 ms half sine pulse (as per IEC60068-2-27)
• Drop: 1m
• Encapsulation: IP67
• Certification: IP67, FCC, CE, RoHS, EAC, WEEE, UKCA, un38.3

Physical

• Weight : =590 g
• Size: 219×88×66 mm

Included in box...

• Guide TR650
• External LRF
• Extended Picatinny Base
• Type C cable
• 5V 2A adapter
• 18650 battery
• Battery charger
• Lens cap
• Eye mask
• Quick start guide
• Warranty card

The TU Gen2 Series is equipped with a high-sensitivity thermal sensor of 12μm and a 1440×1080 HD AMOLED display. Paired with the robust PureIR image algorithm, it provides users with a more vivid and detailed visual experience. The TU Gen2 Series has undergone meticulous optimization in its detailed design, elevating user-friendly operation. Furthermore, the battery life has seen a substantial extension, resulting in a 20% increase in duration.

High Definition Thermal Sensor

High-quality thermal imaging with 400×300@12μm resolution with clear distinctions allows for improved recognition of animals, their body parts, and even minute elements such as branches, leaves, grass, and the landscape.

1440×1080 AMOLED Display

The heat signature captured by the thermal image can be shown on the display using the picture-in-picture (PIP) feature, significantly enhancing the comfort of observation.

PureIR Adaptive Dynamic Filtering Algorithm (PureIR)

The PureIR combining 3DNR and PureIR adaptive filtering algorithms delivers high-sensitivity thermal images, reducing image distortion and enriching detail even for distant targets.

Infrared detector

• Detector type: Uncooled VOx Infrared
• Detector resolution and pitch: 400 × 300, 12 μm
• Spectral range: 8 to 14 μm
• NETD: ≤30 mk
• Frame rate: 50 Hz

Lens

• Focal length: 35 mm; F1.0
• Focus: Manual
• Field of View: 7.8° × 5.9°
• Optical zoom: 2.65x
• Digital zoom: 1x ~ 4x

Display

• Display type: 0.39" AMOLED
• Resolution: 1440 x 1080
• Eyepiece: Exit pupil distance≥ 48mm; Diopter: +/- 4 to; Zoom: 14x
• Video output: Digital video

Power

• Battery type: Single Replaceable 18650 battery
• Battery life: ≥ 12 hours

Interface

• USB: Type C
• Video Interface: Micro HDMI
• Tube Diameter: 30mm
• Memory Capacity: 128 gb
• Language Settings: English / Russian / German / French / Italian / Spanish / Japanese / Korean / Polish

Range Performance

• Detection range: 1000 m

Functions

• Scene modes: Enhanced, Highlight and Natural
• Color palettes: Black Hot, White Hot, Red Hot, Iron Hot, Blue Hot
• PIP: Available
• Hot spot tracking: Available
• WIFI: 2.4 G
• Supported Application: TargetIR
• Firmware OTA: Upgrade device firmware via app connection

Environmental

• Operating temperature range: -30°C to 50°C
• Storage temperature range: -40°C to 70°C
• Humidity: 10 % to 95 % non-condensing
• Shock: 800 G at 1 ms half-sine pulse
• Encapsulation: IP67
• Certification: FCC, CE, RoHS, EAC, un38.3

Physical:

• Weight: ≤ 990 g
• Dimensions: 377 × 107 × 99 mm

Included in box...

• Device
• Lens cap
• Eye masks
• 5V2A adapter (US, Britain, Australia and Europe)
• Desktop charger
• Customized battery ×2
• Extended clip ×2
• USB Type-C cable
• Micro HDMI cable
• Quick start guide

Combining compact size & weight, the Thermtec Vidar series represents the latest in thermal scope technology. The Vidar series are designed for professional users without compromising on quality.

All models are equipped with Wi-Fi, as well as a photo and video recording capability that supports memory cards with a capacity of up to 64 GB. Thanks to advanced image calibration algorithms (NUC), these thermal imagers have been adapted to silent operation without the use of the shutter to ensure image is continuously displayed during shooting. They have are 6 color palettes, 7 different reticles and 5 autonomous profiles for different calibers or shooting ranges, as well as many additional functions, including the Picture in Picture mode, quick reticle zeroing or the ability to being connected to smartphones

The devices are powered by replaceable lithium-ion batteries (2x 18350 or 2x 18500), which enable up to 10 hours of use. The Vidar series products meet demanding water resistance standards and are IP67 certified.

Compact & Light

Lightweight and extremely compact, the Vidar is the perfect companion on any hunting or observational trip.

Non-Shutter Correction Technology

Invisible, background calibration means the screen will never freeze and there is no noisy shutter to alert your quarry.

Automatic Zeroing

The unique automatic zeroing function is the fastest, simplest zeroing system there is; just take a shot and let the Vidar set zero for you.

Real-time APP Notification

The “Smart Thermal” APP would instantly pop up a notification while

detecting the target to avoid any distraction.

High Thermal Sensitivity

The Vidar’s NETD ≤25mK sensor captures the smallest detail even the target and background are almost at the same temperature.

Automatic Object Detection

The Vidar can detect and identify the target while an object entering its field of view to avoid any miss.

High-Precision Zoom

Smooth & rapid 1.0-5.0X HD zooming ensures excellent sharpness and the highest resolution of details from minimum to maximum magnification.

Two Way Wi-Fi Connection

Support both Wi-Fi and hotspot connections; Real-time image transmission

64G storage

A 64GB of memory card enables a large storing of photos and videos.

Easy Battery Installation

The battery's anode and cathode can be installed interchangeably, helping users to complete the battery replacement more quickly at night.

IP67 Protection Rate

Provided with IP67-rated weatherproof performance, it is protected from heavy rainfall, snow, smoke, smog, or dust.

Specifications:

• Resolution, pixel   384*288/12
• Spectral   8-14µm
• NETD   ≤25mk
• Frame rate   50HZ
• Objective lens   35mm, F/1.0
• Field of view   7.5°x5.6°
• Magnification   3.2X
• Digital zoom   1 - 5X continuous zoom
• Eye relief   45mm
• Exit pupil   6mm
• Diopter   -5 ~ +5
• Click range, mm @100 m (H/V)   3,6m/3,6m
• Reticle   7
• Rectile color   Black and white
• Display type   AMOLED
• Resolution, pixel   1024x768
• Display size   0.39 inch
• Color palette   6
• Max. recoil power on rifle  600J
• Mounting brackets included  QD Standard Picatinny Rail
• Shooting record   Support
• RAV   Yes
• Auto zeroing   Yes
• Manual zeroing   Yes
• Zeroing profiles   5
• Picture-in-picture   Yes
• Image calibration   Via lens cover
• Photo/video playback   Yes
• Inbuilt memory   64G
• Magnetic interface   Data transfer
• Wi-Fi   Yes
• Replaceable battery   18650x2
• Battery reverse connection   Yes
• Battery life   14h
• Operating temperature   -20℃—+50℃
• IP rating   IP67
• Weight, g   591
• Size, mm   160x60x70

Range Detection

                  Object                              Distance

• 0.2m Tall (Bird)                        200 m
• 0.3m Tall (Rabbit)                    300 m
• 0.5m Tall (Wolf/Dog)                500 m
• 0.7m Tall (Boar)                       700 m
• 1.8m Tall (Human)                 1800 m
• 4.0m Tall (Car)                       3889 m

Included in box:

• Vidar scope
• Allen keys and screw
• Lithium battery (4pcs)
• Magnetic charge cable
• Picatinny rail
• Manual
• Eyepiece hood

Guide TU435 3.0 400x300 35mm Thermal Scope

The TU 3.0 Series redefines precision optics with advanced thermal imaging, modular design, and AI powered performance. Offered in six sub-series—from ultra-light compact units to dual-spectrum, longrange solutions—they meet the demands of hunters, professionals, and tactical users alike. Featuring AI enhanced imaging, shutterless design, ergonomic controls, IP68 protection, and dual-band Wi-Fi, they deliver reliable performance in any environment.

Hyper-Light Algorithm Ultra-Premium Visuals

Powered by next-gen sensors and the Hyper-light algorithm, the product boosts image quality on multiple levels through improved clarity, reduced noise, optimized contrast, and enhanced resolution of fine details.

Lightweight Design Compact Housing

Compared to the previous generation, TU 3.0 adopts a more compact and lightweight design, making it over 200g lighter than its predecessor with the same configuration. Its slim, metallic housing provides a comfortable grip.

Shutterless Design Uninterrupted Visuals

The innovative shutterless 3.0 technology eliminates the clicking sound and image freezing, ensuring uninterrupted real-time footage during actual hunts, in case any shots are lost or missed during calibration.

Seamless Control Easy Focus & Zoom

Built on extensive field testing and hunter feedback, TU 3.0 was refined in every detail—from the focus wheel to the zoom lever and button layout. The ergonomic design is crafted for comfort and intuitive control.

Rugged Design All-Weather Reliability

Engineered for all-weather reliability, TU 3.0 performs flawlessly in rain, snow, or dust. It features shock resistance up to 6000J to withstand recoil and an IP68 waterproof rating for demanding outdoor missions.

Specifications for Guide TU435 3.0 400x300 35mm Thermal Scope:

Sensor:

• Type: Uncooled VOx Infrared Detector, 8 to 14µm
• Resolution: 400×300@12µm
• NETD: 20mK
• Frame rate: 50 Hz

Lens:

• Objective lens: 35mm, F1.0
• Field of view: 7.4°×4.4°
• FOV m@100m: 13×8
• Magnification: 4.4x~17.6x
• Detection range: 1800m/1950yd
• Focus: Manual

Display:

• Display type: 0.49'' AMOLED 1920×1080
• Color palettes: White Hot, Black Hot, Red Hot, Green Hot, Iron Red, Blue Hot, Sepia
• Eyepiece: Eye relief: 48mm; Diopter -5 to +5; Zoom: 14x

Hardware:

• WIFI: 2.4G, 5G
• Interface: USB-C (Charge/USB2.0)
• Tube diameter: Standard 30 mm
• Others: Microphone, Bluetooth

System:

• Recording function: Photo/Video (Audio recording included)
• Memory capacity: 128GB

Power:

• Battery type: 18500 ×1 Battery (Built-in) and 18650 ×1 Battery (External)
• Operating time: 12 hours

Environmental:

• Operating temp: -20°C to 50°C / -4°F to +122°F
• Shock: 6000J/1200G
• Encapsulation: IP68

Physical:

• Weight (g/oz): 738/26.03
• Size (mm/in): 374×89×76/14.72 ×3.50× 2.99
• Standard: Device, Lens Cover, Eye Mask, Quick-Release Scope Mount, Carry Bag, 18650 Battery ×2, Battery Charger, 5V 2A Adapter (US or UK or Australia or Europe), USB-A to USB-C Cable, Quick Start Guide, Warranty Card

TR Series is an economical civilian infrared thermal imaging scope that adopts high sensitivity thermal detector with three different lens options 25 mm, 35 mm, and 50 mm. The TR Series offers sharp, detailed images with 384 × 288 IR resolution while retaining accuracy. TR thermal scope also features a compact size, waterproof and dustproof, high shock resistance, rugged and durable, which performs impressively in harsh weather.

Features:

• 384x288 IR Resolution
• 35mm/F1.0 Focal Length
• 7.50°×5.64° Field of View
• 1024×768 Full-Colour AMOLED display
• Extended Picatinny Mount

Infrared detector/Sensor

• Detector type: Uncooled VOx Infrared
• Detector resolution and pitch: 348 × 288, 12 µm
• Spectral range: 8 to 14 µm
• NETD: =30 mk
• Frame rate: 50 Hz

Lens

• Focal length: 35 mm; F1.0
• Focus: Manual
• Field of View: 7.50° × 5.64°
• Optical zoom: 3.3x
• Digital zoom: 1x~4x

Display

• Display type: 0.39" OLED HD
• Resolution: 1024 x 768
• Eyepiece: Exit pupil distance=48mm; Diopter: +/- 4 to; Zoom: 14x
• Video output: Analog video

Power

• Battery type: Single Replaceable 18650 battery
• Battery life: = 8 hours

Interface

• USB: Type C
• Mechanical interface: Picatinny

Range Performance

• Detection range: 1400 m

Functions

• Scene modes: Enhanced, Highlight and Natural
• Colour palettes: White Hot, Black Hot, Red Hot, Green Hot, Iron Red, Blue Hot
• PIP: Available
• Hot spot tracking: Available
• Rough ranging: Available with APP
• WIFI: 2.4 G
• Supported Application: TargetIR
• Firmware OTA: Upgrade device firmware via app connection

Environmental

• Storage temperature range: -45°C to 70°C
• Operating temperature: -30°C to 50°C
• Humidity: 10 % to 95 % non-condensing
• Shock: 800 G at 1 ms half-sine pulse
• Drop: 1 m
• Encapsulation: IP67
• Certification: IP67, FCC, CE, RoHS, EAC, WEEE, UKCA, un38.3

Physical:

• Weight: = 540 g
• Dimensions: 208 × 88 × 66 mm

Included in box...

• Guide TR430
• Extended Picatinny Base
• Type C cable
• 5V 2A adapter
• 18650 battery
• Battery charger
• Lens cap
• Eye mask
• Quick start guide
• Warranty card

Guide TU425C 3.0 400x300 25mm Thermal Scope

The TU 3.0 Series redefines precision optics with advanced thermal imaging, modular design, and AI powered performance. Offered in six sub-series—from ultra-light compact units to dual-spectrum, longrange solutions—they meet the demands of hunters, professionals, and tactical users alike. Featuring AI enhanced imaging, shutterless design, ergonomic controls, IP68 protection, and dual-band Wi-Fi, they deliver reliable performance in any environment.

Touch to Control Infinite Eye Relief

The TU C 3.0 Series features an innovative 1.43” touchscreen that changes how users observe and control the device. With infinite eye relief, users can enjoy more comfortable viewing without worrying about recoil.

LPVO Style Smallest of the Series

By adopting a LPVO style design, the TU 3.0 Series revolutionarily combines ultra-compact housing with advanced thermal technology, providing a superior size and weight experience compared to traditional scopes.

Hyper-Light Algorithm Ultra-Premium Visuals

Powered by next-gen sensors and the Hyper-light algorithm, the product boosts image quality on multiple levels through improved clarity, reduced noise, optimized contrast, and enhanced resolution of fine details.

Shutterless Design Uninterrupted Visuals

The innovative shutterless 3.0 technology eliminates the clicking sound and image freezing, ensuring uninterrupted real-time footage during actual hunts, in case any shots are lost or missed during calibration.

Ergonomic Design Easy to Operate

After rounds of field testing, we evaluate the design features based on hunters’ feedback, adjusting and refining them to meet user habits. The focus wheel, zoom lever and button layouts are crafted with ergonomic detail for intuitive control.

Specifications for Guide TU425C 3.0 400x300 25mm Thermal Scope:

Sensor:

• Type: Uncooled VOx Infrared Detector, 8 to 14µm
• Resolution: 400×300@12µm
• NETD: 20mK
• Frame rate: 50 Hz

Lens:

• Objective lens: 25mm, F1.0
• Field of view: 8.2°×8.2°
• FOV m@100m: 14×14
• Magnification: 0.7x~2.8x
• Detection range: 1300m/1400yd
• Focus: Manual

Display:

• Display type: 1.43'' AMOLED 466×466
• Color palettes: White Hot, Black Hot, Red Hot, Green Hot, Iron Red, Blue Hot, Sepia

Hardware:

• WIFI: 2.4G, 5G
• Interface: USB-C (Charge/USB2.0)
• Tube diameter: Standard 30 mm
• Others: Microphone, Bluetooth

System:

• Recording function: Photo/Video (Audio recording included)
• Memory capacity: 32GB

Power:

• Battery type: 18500 ×1 Battery (Built-in) and 18650 ×1 Battery (External)
• Operating time: 12 hours

Environmental:

• Operating temp: -20°C to 50°C / -4°F to +122°F
• Shock: 6000J/1200G
• Encapsulation: IP68

Physical:

• Weight (g/oz): 438/15.45
• Size (mm/in): 245×89×70/9.65×3.50×2.76
• Standard: Device, Lens Cover, Quick-Release Scope Mount, Carry Bag, 18650 Battery ×2, Battery Charger, 5V 2A Adapter (US or UK or Australia or Europe), USB-A to USB-C Cable, Quick Start Guide, Warranty Card

Guide TU425SE 3.0 400x300 25mm Thermal Scope

The TU 3.0 Series redefines precision optics with advanced thermal imaging, modular design, and AI powered performance. Offered in six sub-series—from ultra-light compact units to dual-spectrum, longrange solutions—they meet the demands of hunters, professionals, and tactical users alike. Featuring AI enhanced imaging, shutterless design, ergonomic controls, IP68 protection, and dual-band Wi-Fi, they deliver reliable performance in any environment.

LPVO Style Ultra Light & Compact

By adopting a LPVO style design, the TU SE 3.0 Series revolutionarily combines ultra-compact housing with advanced thermal technology, providing a superior size and weight experience compared to traditional scopes.

Hyper-Light Algorithm Ultra-Premium Visuals

Powered by next-gen sensors and the Hyper-light algorithm, the product boosts image quality on multiple levels through improved clarity, reduced noise, optimized contrast, and enhanced resolution of fine details.

Shutterless Design Uninterrupted Visuals

The innovative shutterless 3.0 technology eliminates the clicking sound and image freezing, ensuring uninterrupted real-time footage during actual hunts, in case any shots are lost or missed during calibration.

Tailored for Hunters Seamless Control

After rounds of field testing, we evaluate the design features based on hunters’ feedback, adjusting and refining them to meet user habits. The focus wheel, zoom lever and button layouts are crafted with ergonomic detail for intuitive control.

Rugged, Durable High Protection

Considering the harsh environment in the field, the scope must be sufficiently durable and sturdy. It features shock resistance up to 6000J to withstand recoil and an IP68 waterproof rating.

Specifications for Guide TU425SE 3.0 400x300 25mm Thermal Scope:

Sensor:

• Type: Uncooled VOx Infrared Detector, 8 to 14µm
• Resolution: 400×300@12µm
• NETD: 20mK
• Frame rate: 50 Hz

Lens:

• Objective lens: 25mm, F1.0
• Field of view: 10.3°×6.2°
• FOV m@100m: 18×11
• Magnification: 3.1x~12.4x
• Detection range: 1300m/1400yd
• Focus: Manual

Display:

• Display type: 0.49'' AMOLED 1920×1080
• Color palettes: White Hot, Black Hot, Red Hot, Green Hot, Iron Red, Blue Hot, Sepia
• Eyepiece: Eye relief: 48mm; Diopter -5 to +5; Zoom: 14x

Hardware:

• WIFI: 2.4G, 5G
• Interface: USB-C (Charge/USB2.0)
• Tube diameter: Standard 30 mm
• Others: Microphone, Bluetooth

System:

• Recording function: Photo/Video (Audio recording included)
• Memory capacity: 32GB

Power:

• Battery type: 18500 ×1 Battery (Built-in) and 18650 ×1 Battery (External)
• Operating time: 12 hours

Environmental:

• Operating temp: -20°C to 50°C / -4°F to +122°F
• Shock: 6000J/1200G
• Encapsulation: IP68

Physical:

• Weight (g/oz): 575/20.28
• Size (mm/in): 311×89×76/12.24×3.50×2.99
• Standard: Device, Lens Cover, Eye Mask, Quick-Release Scope Mount, Carry Bag, 18650 Battery ×2, Battery Charger, 5V 2A Adapter (US or UK or Australia or Europe), USB-A to USB-C Cable, Quick Start Guide, Warranty Card

Guide TJ430L Handheld Thermal Imaging Monocular with Laser Range Finder (LRF)

Embark on nighttime explorations with the TJ LRF Series thermal handheld, a top pick for hunters. Equipped with exceptional thermal imaging technology, this device features a high-sensitivity infrared detector that enables clear night vision. The Full-HD display enhances these benefits, while two-hand operation, laser ranging, video recording, and 12-hour battery life make it the perfect companion for nighttime escapades.

Welcome to the big screens. TJ LRF Series - Handheld Thermal Imaging Monocular

Features:

12um high-sensitivity infrared detector

By utilizing a highly sensitive IR detector with a NETD<25mK, even the slightest temperature differences, can be distinguished resulting in sharper and clearer imaging.

1920 X 1080 AMOLED Display

The eyepiece features a 1920x1080 high-definition AMOLED screen, allowing for a visual experience with vibrant colors and excellent image quality. This significantly enhances the comfort of observation.

35mm F1.0 focal length

Multiple focal lengths give TJLRF Series stronger capabilities and more options in different environments.

1000m laser ranging

The built-in laser rangefinder provides a long detection range of up to 1000m, improving the capability to obtain the target distance and the long-distance perception.

Thermal Monocular Specifications

Sensor

• Type: Uncooled VOx Infrared Detector, 8 to 14 µm
• Resolution: 400×300@12µm
• NETD: 25mK
• Frame rate: 50Hz

Lens

• Objective lens: 35mm, F1.0
• Field of view: 7.9°×5.9°
• FOV m @100m: 14×10
• Magnification: 4.25x~17.0x
• Detection range: 1800m/ 1950yd

Display

• Display type: 0.39'' AMOLED 1920x1080
• Frame Rate: 50 HZ
• Color palettes: White Hot, Black Hot, Red Hot, Green Hot, Iron Red, Blue Hot, Sepia
• Eyepiece: Exit pupil distance 16 mm; Diopter: -6 to +6; Zoom: 18x

Hardware

• Laser rangefinder: 1000m/ 1090yd
• WIFI: 2.4G & 5G
• Interface: USB Type-C (Power supply/USB2.0)
• Others: Microphone, Compass, Gyroscope, Bluetooth

System & Power

• Recording function: Photo/Video (Audio recording included)
• Memory capacity: 32GB
• Battery type: 2 replaceable 18650 batteries
• Operating time: 12 hours

Environmental & Physical

• Operating temp.: -20 °C to 50 °C/ -4°F to +122°F
• Encapsulation: IP67
• Weight(g/oz): 583g / 20.56 oz
• Size(milimetres): 243 × 97 × 66 mm
• Size(Inches): 9.57 × 3.82 × 2.60"

Guide TJ430L comes with...

• Guide TJ430L thermal handheld monocular
• Wrist strap
• Battery charger
• 2x 18650 battery
• 5V 2A adapter
• USB Type-C cable
• Quick use guide
• Warranty card
• Product Manual: Guide TJ Series User Manual
